Allgemeine Spezifikationen
Transducer
2 x 57 mm-Tieftöner
Nennleistung
2 x 15 W
Frequenzbereich
60 Hz – 20 kHz (-6 dB)
Rauschabstand
80 dB
Eingangsanschlüsse
Wi-Fi, Bluetooth®, Aux-in
Gewicht
1.120 g
Energieversorgung
100-240 V AC, 50/60 Hz, 30 Watt
Energieverbrauch im Ruhezustand
2,0 Watt
Dimensions
Verpackungsabmessungen (B x T x H)
350 mm x 240 mm x 140 mm
Produktabmessungen (B x T x H)
316 mm x 147 mm x 131 mm
Control and Connection Specifications
Bluetooth® Version
4.2
Frequenzbereich für die Bluetooth®- Übertragung
2402 − 2480 MHz
Bluetooth-Übertragungsleistung
< 4 dBm
Bluetooth-Übertragungsmodulation
GFSK, π/4 DQPSK, 8DPSK
5 G WLAN-Übertragungsfrequenzbereich
5,150~5,350 GHz, 5,470~5,725 GHz, 5,725~5,825 GHz
5 G WLAN-Übertragungsleistung
< 20 dBm (EIRP)
5 G WLAN-Modulation
OFDM, BPSK, QPSK, 16QAM, 64QAM, 256QAM
5 G WLAN-Netzwerkkompatibilität
IEEE 802.11 n/ac
2,4 G WLAN-Übertragungsfrequenzbereich
2.412 – 2.472 MHz (2,4 GHz ISM-Band, USA
2,4 G WLAN-Übertragungsleistung
<20dBm (EIRP)
2,4 G WLAN-Modulation
OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
2.4 G WLAN-Netzwerkkompatibilität
IEEE 802.11b/g/n
- WLAN-Lautsprecher JBL Playlist
- Kurzanleitung
- Landesspezifische(s) Netzkabel
- Sicherheits- und Garantieblatt

Bei JBL Playlist-Lautsprechern ist Chromecast bereits integriert, so dass du sofort deine Lieblingsmusik auf deinen bevorzugten Apps, Radiosendern oder Podcasts genießen kannst - und zwar über sämtliche Geräte. Du kannst die Lautsprecher mit deinen iOS- oder Android-Geräten überall im Haus steuern - iPhone®, iPad®, Android™-Handy oder Tablet, Mac® oder Windows®-Laptop oder Chromebook.
Handbücher und Downloads
Die neuesten Bedienungsanleitungen, Kurzanleitungen und Dokumente.
Search Result For ""
JBL Playlist wurde bewertet mit
von
5 von
168.
Rated 5 von
5
von
JemmyP aus
Easy to use and looks great!
I've been looking for an easy to use and aesthetically pleasing wireless speaker for some time now, and with the JBL Playlist I think I've found the one!
I've had it just over a month th and never had any problems connecting, playing or linking any of my devices. The sound is great, inside or out and fills the entire space!
The only thing that could improve this, would by to make this wireless and not have to be plugged into the mains power.
If you're looking for a well priced, decent audio speaker which looks great, then look no further!
Veröffentlichungsdatum: 2017-07-27
Rated 5 von
5
von
Grahame7 aus
This may be what you want to hear!
The sound is of a good quality. The Bass & Treble are fine. It works - both Bluetooth & Chromecast. I have it running from Google Play Music loaded in the Chrome browser on my laptop. Also from a Google Pixel mobile phone. Check out the best Music Player App on Android - Cloud-Player by DoubleTwist - it works well to play your music from google Drive or MS One Drive. JBL, please keep including Chromecast. If you buy a few of these you can build an all over the house music system sourced from your phone or laptop by using Chromecast Groups. If there is a negative it's that the lead is too short (but easy to replace with a longer one for a fiver). And now, the answer to the Acid Test question: Yes, I would buy another.
Veröffentlichungsdatum: 2018-02-19
Rated 5 von
5
von
CodyK aus
Impressed for a small speaker
The quality of the sound is great for small wireless speaker. I think it is perfect for a bedroom or other area where you aren't expecting a huge thumping sound. It is plenty loud and the quality improves after it is used for a while. The chromecast works awesome! As stated in many professional views, this is a great value speaker!
Veröffentlichungsdatum: 2018-07-19
Rated 5 von
5
von
Andy1977 aus
Chromecast goodness
I bought this speaker a couple of weeks ago and it has been excellent. The main reason I went for this model was because of the built in Chromecast, it works flawlessly and was a breeze to set up. The sound quality is quite reasonable for this price point too.
Veröffentlichungsdatum: 2018-01-11
Rated 5 von
5
von
Hestad aus
Perfect for small-medium rooms using Google Cast
I had 5 audio cast devices in my house, spread over 3 floors + a garage, and I needed some more speakers on smaller rooms. Now added two JBL Playlists, on a bedroom and a hobby room.
Works great for this purpose. For my taste they do not deliver enough sound in volume and bass, even if paired, to be used in larger rooms, but I would not have expected that anyway.
Veröffentlichungsdatum: 2018-03-30
Rated 3 von
5
von
Niggi aus
Technik noch nicht ausgereift..
Grundsätzlich funktioniert das Pairing über WLAN. Leider wird man das Gefühl nicht los, dass das alles noch nicht ausgereift ist - und das ist nicht die Schuld von JBL: Streamen ich den kompletten Ton meines Handys auf den Lautsprecher, gibt es keine Probleme. Verwende ich jedoch den Cast-Button in der Google Musik App, passiert oftmals gar nichts. Ich habe den Eindruck, dass Google seine eigene Technologie noch nicht so richtig unter Kontrolle hat. Die Box an sich klingt gut und hat ein durchdachtes Design. Auch das koppeln über Bluetooth funktioniert problemlos.
Fazit: JBL hat eine solide Box genau, Google muss noch nachbessern!
Veröffentlichungsdatum: 2017-12-27
Rated 5 von
5
von
Keir aus
Great Sounding Speaker
Won this speaker in a recent competition held by JBL. The speaker is amazing, pretty compact and and amazing punch bass sound; it's great..thank you JBL.
Veröffentlichungsdatum: 2017-10-10
Rated 5 von
5
von
SeanP aus
Small but powerful
Real packs a punch for it's small size.
Very clear sound too.
Great value all in all
Veröffentlichungsdatum: 2017-11-16
Can you pair two of these together and play the same sound via Bluetooth?
Thank you for your inquiry.
If your phone supports dual Bluetooth you can connect both speakers with your phone and make them play from the same source. You would have to pair them each time you want them to play like this, however. The WiFi set up via the Google Home app is therefore the much more elegant solution for this scenario.
If you have further questions, do not hesitate to contact us by phone, email or chat to get individual help.
Please refer to https://en.harmanaudio.com/support-contact.html#ns for more information.
Many Thanks.
Veröffentlichungsdatum: 2019-02-01
Ljud från högtalaren och bild från you tube är inte synkade hur gör jag?
Hej Evax, tak for at du købte JBL!
Din Playlist højttaler er konstrueret som en ren audio-højttaler, og kan ikke benyttes til lyd i kombination med billede, da der altid vil være delay. I nogle få tilfælde kan du justere delay på billedet på dit TV, men det er ikke sikkert at du kan, eller at du kan justere det tilstrækkeligt. Desværre kan du ikke benytte den som du ønsker. Jeg beklager.
Veröffentlichungsdatum: 2019-01-16
Heb meerdere playlist boxen in mijn bezit. Sinds een aantal dagen doet een box het niet meer. Resetten lukt niet en box is niet meer te benaderen. Wat kan ik doen alles werkend te krijgen?
Om uw vraag goed te kunnen beantwoorden, zouden onze productspecialisten graag nog wat probleemoplossing proberen.
Daarom verzoeken we u vriendelijk om rechtstreeks contact op te nemen met het Harman Customer Support team via telefoon, e-mail of chat.
Meer informatie vindt u op https://www.harmanaudio.nl/support-contact.html
Dank u voor uw medewerking.
Veröffentlichungsdatum: 2019-01-14
Kan ik de Playlist 'factory' resetten? Door Media Markt heeft hij een naam gekregen die ik eruit wil hebben. En er staat een ander google account in.
Om uw vraag goed te kunnen beantwoorden, zouden onze productspecialisten graag nog wat probleemoplossing proberen.
Daarom verzoeken we u vriendelijk om rechtstreeks contact op te nemen met het Harman Customer Support team via telefoon, e-mail of chat.
Meer informatie vindt u op https://www.harmanaudio.nl/support-contact.html
Dank u voor uw medewerking.
Veröffentlichungsdatum: 2019-01-07
Die Ansteuerung mit der Amazon Music app funktioniert nicht richtig. Die Verbindung zur Playlist dauert lang und bricht oft wieder ab. Keine stabile Verbindung. Teilweise viele Verbindungsversuche nötig. Gibt es ein Softwareupdate für die Playlist?
Was bei den JBL Playlist Gerät zu riesigen Problemen führen kann, wenn sich das Smartphone automatisch per Bluetooth mit der JBL Playlist verbindet. Dann funktioniert die wlan Funktion mit Chromecast nicht (bzw nicht richtig). Die Lösung ist einfach, am Smartphone Bluetooth Kopplung lösen! (Alternativ das automatische Koppeln mit Bluetooth Geräte deaktivieren.)
Veröffentlichungsdatum: 2018-12-30
Hallo ich habe seit circa einer woche die JBL Playlist alles war gut und die einrichtung hatt schnell funktioniert und alles, nun wollte ich sie umstellen Doch jetzt geht nichts mehr Rest bringt garnicht´s sie startet dauernd neu alles leuchtet HILFEEE!
Was bei den JBL Playlist Gerät zu riesigen Problemen führen kann, wenn sich das Smartphone automatisch per Bluetooth mit der JBL Playlist verbindet. Dann funktioniert die wlan Funktion mit Chromecast nicht (bzw nicht richtig). Die Lösung ist einfach, am Smartphone Bluetooth Kopplung lösen! (Alternativ das automatische Koppeln mit Bluetooth Geräte deaktivieren.)
Veröffentlichungsdatum: 2018-12-30
Während des Musikbetriebs über WLAN passiert folgendes: kein Connect über GoogleHomeApp, WLAN Verb. funktioniert nicht mehr, Symbol WLAN leuchtet nicht mehr, ... das laufend. Habe die JBL zurückgesetzt und neu eingebunden, WLAN Router gewechselt, was tun?
Was bei den JBL Playlist Gerät zu riesigen Problemen führen kann, wenn sich das Smartphone automatisch per Bluetooth mit der JBL Playlist verbindet. Dann funktioniert die wlan Funktion mit Chromecast nicht (bzw nicht richtig). Die Lösung ist einfach, am Smartphone Bluetooth Kopplung lösen! (Alternativ das automatische Koppeln mit Bluetooth Geräte deaktivieren.)
Veröffentlichungsdatum: 2018-12-30
Playlist keeps flashing, then bluetooth mode lights up, then power, and cycles back. Pressing and holding volume up and BT won't rest it, and the reset button on the back only interrupts the cycle for a quick moment... How may this be fixed?
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Veröffentlichungsdatum: 2018-12-20
